4.7
3300 CC
DieselKey Specifications of Tata ULTRA T.16
Power
180 HP
GVW
16140 KG
Wheelbase
3920 MM
Engine
3.3L NG BS6 Engine
Fuel Tank
160 Ltr.
Payload Capacity
11100 KG
No. of Tyres
6
Mileage
6.5 KMPL
Tata ULTRA T.16 Specs & Features
Performance
Engine i | 3.3L NG BS6 Engine |
Engine Norm i | BS-6 |
Gradeability i | 26 (%) |
Engine Capacity i | 3300 CC |
Power i | 180 HP |
Engine Cylinders i | 4 |
Max Torque i | 475 Nm |
Max Speed i | 80 KMPH |
Fuel Tank i | 160 Ltr. |
GVW i | 16140 KG |
Payload Capacity i | 11100 KG |
Kerb Weight i | 4920 KG |
Mileage i | 6.5 KMPL |
Dimensions
Length i | 7495 MM |
Width i | 2440 MM |
Height i | 2630 MM |
Wheelbase i | 3920 MM |
Ground Clearance i | 235 MM |
Minimum Turning Radius i | 13900 MM |
Brakes Suspension
Brakes i | Dual Circuit Full Air "S" Cam Brakes With Auto Slack Adjuster (Drum - Drum) & ABS |
Parking Brakes i | Graduated valve controlled spring brake chamber integral with rear brake |
Front Axle i | Forged "I" beam reverse Elliot type |
Rear Axle i | TATA RA108R Single reduction hypoid gears, fully floating Benjo Axle (RAR - 6.42) |
Front Suspension i | Parabolic leaf spring, hydraulic double acting shock absorbers |
Rear Suspension i | Semi elliptical leaf spring, hydraulic double acting shock absorbers |
Abs i | Yes |
Clutch Transmission
Clutch i | Single Plate Dry Friction Type, 330 mm |
Gearbox i | 6 Forward + 1 Reverse |
Steering i | Tilt & Telescopic Power Steering |
Transmission i | Manual |
Power Steering i | Yes |
Body Cabin
Body Option i | Customizable body |
Chassis Type i | Chassis with Cabin |
Seating Capacity i | Driver + 2 Passenger |
Cabin Type i | Day Cabin |
Tiltable Steering i | Yes |
Arm Rest i | yes |
Tyre
Front Tyre i | 9 R 20 - 16 |
Rear Tyre i | 9 R 20 - 16 |
Tubeless Tyre i | No |
